Toyota Yaris Headlights Projector 2008-2013

VLAND Toyota Yaris (NCP93) Headlights 2005–2013 — LED DRL, Projector Low Beam | Also Fits Toyota Vios/Belta

OEM-style headlight assemblies for the second-generation Toyota Yaris Sedan (NCP93, 2005–2013) — also marketed as Vios/Belta. Bolt on using factory mounts and connectors. White LED DRL, projector low beam (H7/D2H, bulbs not included) and reflector high beam (H1, bulb not included).

Fitment

• Toyota Yaris Sedan (NCP93) — 2005–2013
• Toyota Vios (2nd Gen NCP93) — 2005–2013
• Also known as: Toyota Belta / Toyota Limo
• Body style: sedan only
• LHD and RHD compatible

Highlights

• LED daytime running light (white) for a clean, modern signature.
• Projector low beam for focused output (accepts H7/D2H — not included).
• Reflector high beam (accepts H1 — not included).
• OEM-style mounting and multi-pin connectors; seals and housings built for daily use (IP67).

 

Install notes

• Mounts to factory points; reuse OE hardware where applicable.
• Turn signal wiring: splice the vehicle’s original turn-signal wire to the 1156 bulb-socket lead supplied on the lamp to activate the indicator.
• Verify low/high, DRL, and turn functions before final tightening.
• Professional installation recommended.

What’s in the box

• Left + Right headlight assemblies
• User / install guide

Specs

Product type	Headlights (pair)
Housing / Lens	ABS/PP housing (black) / Clear PC lens
Low beam	Projector — H7/D2H (bulb not included)
High beam	Reflector — H1 (bulb not included)
DRL	LED (white)
Turn signal	Uses original amber bulb via 1156 socket lead (see install note)
Color temperature	~6000–6500 K (with typical bulbs)
Ingress	IP67
Warranty	1 year from delivery date

OEM & parts cross-references (examples)

8113052D30,8113052E20,8117052D30,8117052E20,81170-WB001,81130-WB001.

Package & weight

Carton: 57.5 × 27.5 × 45.5 cm • Gross ≈ 6.6 kg (Net ≈ 4.8 kg)
